Quest QM18SA Powered 18" Sub with DSP 1000 Watts RMS
Availability: Available
Quest Engineering
QM18SA Sub
QM18SA Powered Sub with DSP
The QM18SA is an active powered 18" sub woofer which is suitable for both mobile applications and installation. The QM18SA features inbuilt 24bit/96kHz processing. The Class D amplifier produces a continuous 1000 watts of power and is matched with a high efficiency 18" woofer. The cabinet size and shape has been optimised to achieve a balance between portability, SPL and bass depth while weighing less than 41kg.
Road Ready
The QM18SA cabinet is made of 15mm heavy-duty birch plywood and finished with an extremely resilient black coating. The cabinet is fitted with a wrap-around heavy gauge protective steel grille. The QM18SA has been crafted to endure demanding environments and is built with longevity in mind. Convenient threaded holes are provided, if you want it on wheels, just bolt them on.
Big Bass, Plug'n'Play
The Quest Engineers have designed a simplified user control interface which makes setting up and using the sub system extremely easy. The sub bass frequencies are already defined, equalised, and limited to deliver the best results while providing a high passed output to a mid/high cabinet. This high pass output will provide excellent results when paired with the Quest QM450A or similar products. There is also a full range output to deliver the signal to additional QM18SA.
Choose from a variety of Powered Subwoofer online.
Specifications
| Freq. Range (-10dB): | 36Hz~140Hz |
| Max Calculated SPL: | 133dB |
| Frequency Response (-3dB) | 52.5Hz - 92.5Hz |
| Amplifier Power: | 1000W |
| LF Transducer: | 18" / 450mm |
| Crossover Frequency: | 110Hz Preset and Optimised |
| Input Connector: | Female XLR |
| Output Connector: | Male XLR |
| AC Input: | AC220~240V 50Hz/60Hz |
| Net Weight: | 38.5kg |
| Shipping Weight: | 43kg |
| Dimensions (WxHxD): | 700mm x 530mm x 700mm |
| Carton Size (WxHxD): | 790mm x 620mm x 800mm |
| * Quest Engineering reserves the right to make changes in specifications, or products without prior notice. ** The figures shown above are 'real world', usable specifications and are conservative as a result. Quest Engineering does not believe in portraying misleading or exaggerated specifications. |
|
| Specification | Specifications
|
||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Quest Engineering |
||||||||||||||||||||||||||||
| Package | 1 Pack | ||||||||||||||||||||||||||||
Specifications
| Freq. Range (-10dB): | 36Hz~140Hz |
| Max Calculated SPL: | 133dB |
| Frequency Response (-3dB) | 52.5Hz - 92.5Hz |
| Amplifier Power: | 1000W |
| LF Transducer: | 18" / 450mm |
| Crossover Frequency: | 110Hz Preset and Optimised |
| Input Connector: | Female XLR |
| Output Connector: | Male XLR |
| AC Input: | AC220~240V 50Hz/60Hz |
| Net Weight: | 38.5kg |
| Shipping Weight: | 43kg |
| Dimensions (WxHxD): | 700mm x 530mm x 700mm |
| Carton Size (WxHxD): | 790mm x 620mm x 800mm |
| * Quest Engineering reserves the right to make changes in specifications, or products without prior notice. ** The figures shown above are 'real world', usable specifications and are conservative as a result. Quest Engineering does not believe in portraying misleading or exaggerated specifications. |
|
