Power

• Input Voltage: 100~240V AC, 50/60 Hz
• Power Consumption: 265W
• Connection: Neutrik® Powercon – In / Out
• Fuse: T3.15A, 250V

Photometric

• Light Source: 7 pcs Osram® 40W RGBW LED
• Beam Angle: 4 - 36°
• Output: 7000lumen 43000lux @ 3M RGBW at 4°
• PWM: 1200Hz
• LED Lifespan: 60,000 hours

Effects

• Dimming: 0 ~ 100%
• Pixel Control: Yes
• Strobe: 0.5 ~26 Hz
• Zoom: 4 - 36°

Movement 8 / 16 – bit

• Pan: 630° (1.56 sec) / 540° (1.3 sec)
• Tilt: 265° (0.85 sec)

Control

• Protocol: DMX512 (W-DMX™ Optional)
• DMX Channels: 22/51/19/21
• Interface: 5-pin XLR / Artnet interfaces
• RDM: Yes
• Software Upgrade via DMX: Yes
• Built-in Programming: Yes
• Sound Active: Yes
• Display: 2.4″ Colour LCD with battery
• Cooling: Multi Sensor Thermostat Controlled Variable Speed Fan

MISC

• Road Case: Optional
• Rigging: 2pcs Omega Brackets with 1/4-turn Quick Locks

Housing

• Materials: ABS & Steel
• Finishing: Matte black
• IP rating: IP20
• Net Weight: 12 kg
• Overall Size: 324 x 250 x 456 mm
