Applications:

Touring sound

Arenas, stadiums, large-scale events, live theatres, concert halls and clubs

AS310 uses 2x10" LF, 2x6.5"MF and 2x1.73" compress drivers.

2x 10” LF

2x 6.5” MF

2x 2in compression drivers

18in birch structured plywood

Water-resistant texturerd black paint finish

Operating Mode: Bi-amp

Operating Range: 80 Hz – 18kHz (+/- 3dB)

Sensitivity MF/HF 108dB, LF 92dB SPL (1W at 1M)

Nominal Impedance MF/HF 8 ohms, LF 8ohms

Nominal Coverage Angle (-6dB): 110deg horizontal

POWER HANDLING /OUTPUT:

      (LF) 400W RMS - 118dB SPL; 2x 10in dia, 75mm (3in) voice coil

      (MF/HF) 280W RMS- 134dB SPL; 2x 6.5in dia, 44mm (1.73in) voicecoil,

      2x2in dia, 23 mm throat dia

Connections: Speakon NL8 x 2

Suspension Hardware: proprietary rigging system

Dimensions: 330 x 720 x 750mm

Weight: 36.5kg
