Suitable for mid-bass application.
Specifications:
| Nominal Diameter | 300/12 | mm/inch | ||
| Retd Impedance | 8 | ohms | ||
| Power Capacity | 250 | watts | ||
| Sensitivity IW/IM | 98 (+/- 2) | dB | ||
| Frequency Range | 53-3000 | Hz | ||
| Voice Coil Diameter | 63/2.52 | mm/inch | ||
| Magnetic Assembly Weight | 1.60 | kg | ||
| Magnet Diameter | 170 x 80 x 20 | mm/inch | ||
| Product Net Weight | 5.60 | kg | ||
| Resonance Frequency | Fs | 53.20 | Hz | |
| DC resistance | Re | 6 | ohms | |
| Mechanical Factor | Qms | 6.40 | ||
| Electrical Factor | Qes | 0.30 | ||
| Total Factor | Qts | 0.29 | ||
| BL Factor | BL | 16.2 | ||
| Vas | 90.3 | L | ||
| Rp | 88.3 | ohm | ||
| Lp | 54.1 | mH | ||
| Cp | 271.0 | LF | ||
| Le | 1.3 | mH | ||
| MmS | 39.2 | gr | ||
| Xmax | (+/-) 6 | mm | ||
